Installing Kubernetes on Debian 13 Trixie
Fri 21 November 2025I am currently preparing for the Kubernetes administrator certification (CKA). As an exercise, I was already setting up Kubernetes the hard way. Thanks to Kelsey Hightower who provided that great tutorial to the community. That was a very good experience, and I learned a lot about the Kubernetes bootstrapping process.
But I need some more practice with kubeadm for doing the certification, so I choose to bootstrap a Kubernetes
cluster with that tooling as well. The process is documented quite well in the official Kubernetes documentation.
I wrote this article mainly to capture my learning. I found some more background information that I added here
so that article provides a bit more value than the official documentation. Also, I added some more details on how to
practically do the installation on a Debian system.
I manually provisioned three virtual machines with Debian 13 on my hypervisor. One for a control plane and the other two for worker nodes. Kubernetes nodes can be configured to utilize swap memory, but that comes with some caveats. If you don't plan to use swap memory later, you can provision your virtual machines without swap in the first place. Then you don't need to switch it off later.
Here I install with v1.33.5 an older version of Kubernetes. The reason for this is that I would like to upgrade that
cluster manually with kubeadm at some later point. So if you want to install a cluster running the latest Kubernetes,
check for the latest release and use that version.
Control Plane
Pick one of the three virtual machines to be your control plane.
Turn Swap off
If you happen to have swap enabled on your node, you need to disable it first. The default behavior of a kubelet is to fail to start if swap memory is detected on a node. We switch it off by masking the swap unit using systemctl:
$ swapon --show
NAME TYPE SIZE USED PRIO
/dev/sda5 partition 1.7G 0B -2
$ systemctl list-units --type swap
UNIT LOAD ACTIVE SUB DESCRIPTION
dev-disk-by\x2duuid-62a3642e\x2db966\x2d46b4\x2dbb58\x2de453f240e351.swap loaded active active /dev/disk/by-uuid/62a3642e-b966-46b4-bb58-e453f240e351
Legend: LOAD → Reflects whether the unit definition was properly loaded.
ACTIVE → The high-level unit activation state, i.e. generalization of SUB.
SUB → The low-level unit activation state, values depend on unit type.
1 loaded units listed. Pass --all to see loaded but inactive units, too.
To show all installed unit files use 'systemctl list-unit-files'.
$ systemctl mask 'dev-disk-by\x2duuid-62a3642e\x2db966\x2d46b4\x2dbb58\x2de453f240e351.swap'
Created symlink '/etc/systemd/system/dev-disk-by\x2duuid-62a3642e\x2db966\x2d46b4\x2dbb58\x2de453f240e351.swap' → '/dev/null'.
Reboot the machine, then check again for swap:
swapon --show
Swap should be turned off now.
Enable IPv4 packet forwarding
I will use Cilium as CNI for this Kubernetes cluster.
Reading through the Cilium documentation
and Kubernetes documentation
I came to the conclusion that enabling the IPv4 packet forwarding might not be needed as Cilium
takes care of it on its own behalf. But during installation I noticed that kubeadm is actually checking for this
setting in its pre-flight checks before installation. So you need to add it at this point.
First load kernel drivers to make sure they are present before changing the config:
modprobe overlay
modprobe br-netfilter
Then apply new kernel parameters:
# sysctl params required by setup, params persist across reboots
cat <<EOF | tee /etc/sysctl.d/k8s.conf
net.ipv4.ip_forward = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.bridge.bridge-nf-call-iptables = 1
EOF
# Apply sysctl params without reboot
sysctl --system
Check if changes were persisted:
$ sysctl net.ipv4.ip_forward
net.ipv4.ip_forward = 1
$ sysctl net.bridge.bridge-nf-call-ip6tables
net.bridge.bridge-nf-call-ip6tables = 1
$ sysctl net.bridge.bridge-nf-call-iptables
net.bridge.bridge-nf-call-iptables = 1
Debian Packages
Install the needed Debian packages:
apt update
apt install -y ca-certificates curl gpg socat conntrack ipset kmod vim
Install Containerd
We need to install containerd as container runtime first. Make sure to install a compatible version of containerd for your Kubernetes version.
Setup Docker apt repository for installing containerd:
install -m 0755 -d /etc/apt/keyrings
curl -fsSL https://download.docker.com/linux/debian/gpg -o /etc/apt/keyrings/docker.asc
chmod a+r /etc/apt/keyrings/docker.asc
echo \
"deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.asc] https://download.docker.com/linux/debian \
$(. /etc/os-release && echo "$VERSION_CODENAME") stable" | \
tee /etc/apt/sources.list.d/docker.list > /dev/null
apt update
Install containerd:
apt install containerd.io
Now we need to create and modify the config. There are two configuration changes we need to consider:
- We need to use the systemd cgroup driver in /etc/containerd/config.toml with runc.
- Update the reference for the sandbox pause image
containerd config default | tee /etc/containerd/config.toml
sed -e 's/SystemdCgroup = false/SystemdCgroup = true/g' -i /etc/containerd/config.toml
You can use vim to edit /etc/containerd/config.toml and set it to the up-to-date version.
Then restart containerd and check its status:
systemctl restart containerd
systemctl status containerd
Install Helm
Install the Kubernetes package manager Helm:
curl -fsSL https://packages.buildkite.com/helm-linux/helm-debian/gpgkey | gpg --dearmor | sudo tee /usr/share/keyrings/helm.gpg > /dev/null
echo "deb [signed-by=/usr/share/keyrings/helm.gpg] https://packages.buildkite.com/helm-linux/helm-debian/any/ any main" | sudo tee /etc/apt/sources.list.d/helm-stable-debian.list
apt update
apt install helm
Install Kubernetes
We will install Kubernetes now. It's recommended to use the community owned package repositories. You need to add them as they are not available on Debian be default. So we add the v1.33 Kubernetes apt repository:
curl -fsSL https://pkgs.k8s.io/core:/stable:/v1.33/deb/Release.key | gpg --dearmor -o /etc/apt/keyrings/kubernetes-apt-keyring.gpg
echo 'deb [signed-by=/etc/apt/keyrings/kubernetes-apt-keyring.gpg] https://pkgs.k8s.io/core:/stable:/v1.33/deb/ /' | tee /etc/apt/sources.list.d/kubernetes.list
apt update
Install kubeadm, kubelet and kubectl:
apt install -y kubeadm=1.33.5-1.1 kubelet=1.33.5-1.1 kubectl=1.33.5-1.1
Pin the versions for kubeadm, kubelet and kubectl to prevent accidental upgrades:
apt-mark hold kubelet kubeadm kubectl
If you assigned a static IP to you machine, Debian by default already added an entry for it in /etc/hosts.
For instance:
192.168.20.210 debian-controlplane-1.lan debian-controlplane-1
Modify /etc/hosts and add an entry for the control plane endpoint:
echo "$(hostname -i) debian-k8s-endpoint" >> /etc/hosts
Add also the other two worker nodes. So it looks like this eventually:
192.168.20.210 debian-controlplane-1.lan debian-controlplane-1
[...]
# Kubernetes
192.168.20.210 debian-k8s-endpoint
192.168.20.211 debian-worker-1.lan debian-worker-1
192.168.20.212 debian-worker-2.lan debian-worker-2
Initialize the control plane node:
kubeadm init --kubernetes-version 1.33.5 --control-plane-endpoint debian-k8s-endpoint
Configure kubectl for non-root user
Switch to your regular non-root user and configure admin access for kubectl (see also kubeadm init output):
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config
Check on your node:
$ kubectl get nodes
NAME STATUS ROLES AGE VERSION
debian-controlplane-1 NotReady control-plane 5m56s v1.33.5
Install Cilium as CNI
Install Cilium CNI using helm:
helm repo add cilium https://helm.cilium.io/
helm install cilium cilium/cilium --version 1.18.3 --namespace kube-system
You can check connectivity with Cilium tooling.
Worker Nodes
Now we can add additional worker nodes. On each worker node we need to prepare the node (see above):
- Switch off swap (if needed)
- Enable packet forwarding (if needed)
- Install Debian packages
- Install containerd
- Add Kubernetes apt repository
We do not need to install kubectl and Helm.
Install Kubernetes
Install kubeadm and kubelet:
apt install -y kubeadm=1.33.5-1.1 kubelet=1.33.5-1.1
Pin the versions for kubeadm and kubelet to prevent accidental upgrades:
apt-mark hold kubelet kubeadm kubectl
Add Host Entries
You can check your nodes IP address with hostname -i.
Add all host entries to /etc/hosts also on this node.
# Kubernetes
192.168.20.210 debian-k8s-endpoint
192.168.20.211 debian-worker-1.lan debian-worker-1
192.168.20.212 debian-worker-2.lan debian-worker-2
Join the Worker Node
On the control plane node issue a new token and print the join command:
$ kubeadm token create --print-join-command
kubeadm join debian-k8s-endpoint:6443 --token 7dvrku.gk93a26j6o0maiwn --discovery-token-ca-cert-hash sha256:61d474bef805e9c8d14d3ac96a80e5b2031d7b06fecd9296b4aa77ba15755892
On the worker node use that generated join command to join that node to the cluster:
kubeadm join debian-k8s-endpoint:6443 --token 7dvrku.gk93a26j6o0maiwn --discovery-token-ca-cert-hash sha256:61d474bef805e9c8d14d3ac96a80e5b2031d7b06fecd9296b4aa77ba15755892
Watch the console output. After a while check on the control plane node for the nodes:
$ kubectl get nodes
NAME STATUS ROLES AGE VERSION
debian-controlplane-1 Ready control-plane 15h v1.33.5
debian-worker-1 Ready <none> 17s v1.33.5
Additional Control Plane and Worker Nodes
If you want to add additional control plane or worker nodes, just add a new machine as described above for any
additional node. Please be aware that you need to add --control-plane as an option when you want to join a control
plane node with kubeadm join.
When you work with virtual machines on a hypervisor, you probably want to make use of templates to ease your work here.
I was doing this just for the sake of getting some practice with kubeadm.
